Ultrasonic transducer packs
Western Ultrasonics supplies transducer packs for retrofitting older tanks and upgrading existing systems, backed by the expertise to ensure proper installation and performance. Contact us today to find out how we can extend the life and capability of your current equipment.
What Are Transducer Packs
Transducer packs are housings for transducers that convert one form of energy into another. In the case of Ultrasonic cleaning, that means converting electrical energy into sound waves. Whether you are looking to replace old transducers on a cleaner or retrofit an existing steel tank into an ultrasonic cleaner, Western Ultrasonic is here to help you along every step of the way.
Transducer Pack Options
WUI-1006
300 W, 6 transducers, 9.84 x 7.87 in
WUI-1024
1200 W, 24 transducers, 21.65 x 15.75 in
WUI-1012
600 W, 12 transducers, 13.78 x 11.81 in
WUI-1030
1500 W, 30 transducers, 21.65 x 19.69 in
WUI-1042
2100 W, 42 transducers, 25.59 x 25.59 in
WUI-1018
900 W, 18 transducers, 15.75 x 13.78 in
WUI-1036
1800 W, 36 transducers, 23.62 x 21.65 in
How it works
Ultrasonic transducers are mounted on the walls of the tank in various configurations, emitting high-frequency sound waves through the cleaning solution. These sound waves create cavitation — microscopic bubbles that implode on the surface of parts and components, safely dislodging and removing even the most stubborn contaminants. Retrofitting with updated transducer packs allows both new and existing tanks to achieve greater cleaning depth and a wider effective cleaning area.
Mounting
Our transducer packs are self contained and have 6 mounting options
#1 Bottom mount with over the top signal input
#2 Bottom mount with bulkhead input using lead out tubes through the tank bottom with Teflon gaskets
#3 Bottom mount with side bulkhead
#4 Bottom mount same as #1 except no junction box at the top just straight pipe
#5 Side mount over the top
#6 Side mount with bulkhead fitting above the waterline but below the edge - our favorite on large systems
Contact Us
Have a question or ready to get started? Our team is here to help. Whether you need guidance on the right cleaning solution, a recommendation on equipment, or a quote for your application, Western Ultrasonics has the expertise to point you in the right direction.
Fill out the form below or call us during business hours at (780) 462-5858. For quoting purposes, feel free to upload photos or technical drawings of your parts directly through the form.
7363 42 Street NW, Edmonton, Alberta, T6B 2T1
8:30 am to 4:00 pm, Monday to Friday
Frequently Asked Questions
-
The number and type of transducers required depend on several factors — including tank volume, part geometry, and surface area. Western Ultrasonics can assess your specific application and recommend the right system configuration for your needs. Contact us today to get started.
-
The tank material must be stainless steel. Ferrous metals will quickly rust.
-
Retrofitting is a practical solution when an existing tank or system no longer delivers the cleaning power your operation demands. It is also a cost-effective alternative to full equipment replacement when older or underperforming transducers need to be brought up to standard.
